>>>型號:VBS01-EPD 電路板 輸出觸點監視器 8個內部讀回通道

【功能描述】

VBS01-EPD是一款高性能的電路板，具有多種關鍵特性。它具備輸出觸點監視器，能夠讀回并檢測到內部FBM的高覆蓋率故障，當檢測到故障時，允許冗余伙伴自動繼續驅動離散輸出和監控輸入。

VBS01-EPD其內部每通道輸出需求狀態故障檢測功能可以確保輸出狀態的準確性和可靠性。

VBS01-EPD的FBM240具有8個內部讀回通道，每個輸出通道一個，用于驗證輸出是否已更改為請求的狀態。這些通道讀取繼電器終端組件上繼電器觸點兩端的電壓狀態，并在FBM240前面板上的LED上顯示。

每個離散輸出都與其他通道和接地進行電流隔離，保證了輸出的獨立性和安全性。

在配置和通信方面，VBS01-EPD同樣表現出色。它支持中央位置的配置數據備份，采用客戶端/服務器體系結構，服務器最多支持10個同時使用的客戶端。其配置服務器管理系統使得配置數據可以備份、存檔或

復制到另一臺服務器。此外，VBS01-EPD還支持與S+控制器的實時通信，支持的實時接口包括以太網模塊（PNI800或IET800）和串行模塊（ICT01、ICT13A等）。

VBS01-EPD在以太網模件通訊控制器配置中也表現出優秀的冗余協調運用能力，適用于DCS系統、機器人系統以及大型伺服控制系統等備件需求。

總的來說，ABB的VBS01-EPD是一款功能強大、性能穩定的電路板，適用于各種工業自動化和電力系統應用，能夠提供可靠的同步和控制解決方案，確保設備的穩定運行和高效性能。

>>>>型號:VBS01-EPD 電路板 輸出觸點監視器 8個內部讀回通道

【英文介紹】

The VBS01-EPD is a high-performance circuit board with several key features. It has an output contact monitor that reads back and detects high-coverage faults in the internal FBM, allowing redundant partners to

automatically continue driving discrete outputs and monitoring inputs when a fault is detected.

VBS01-EPD Its internal per channel output requirement state fault detection function can ensure the accuracy and reliability of the output state.

VBS01-EPD's FBM240 has eight internal read back channels, one for each output channel, to verify that the output has changed to the requested state. These channels read the voltage status at both ends of the relay

contacts on the relay terminal assembly and are displayed on the LED on the front panel of the FBM240. Each discrete output is electrically isolated from other channels and ground, ensuring the independence and safety

of the output.

In terms of configuration and communication, VBS01-EPD also performs well. It supports configuration data backup in a central location and uses a client/server architecture, with servers supporting up to 10 simultaneous

clients. Its configuration server management system enables configuration data to be backed up, archived, or copied to another server. In addition, VBS01-EPD also supports real-time communication with S+ controllers,

 including Ethernet modules (PNI800 or IET800) and serial modules (ICT01, ICT13A, etc.).

VBS01-EPD also shows excellent redundancy coordination in Ethernet module communication controller configuration, suitable for DCS systems, robot systems and large servo control systems and other spare parts requirements.

Overall, ABB's VBS01-EPD is a powerful and stable circuit board for a wide range of industrial automation and power system applications, providing reliable synchronization and control solutions to ensure stable operation and

efficient performance.
